EVF-2151采用了2個DVX3159A 15"低音音箱,單元、懸掛系統和電氣設計都通過FEA技術進行了優化,保證了在高SPL下失真度超低,清晰度更高。?雙D
EVF-2151采用了2個DVX3159A 15"低音音箱,單元、懸掛系統和電氣設計都通過FEA技術進行了優化,保證了在高SPL下失真度超低,清晰度更高。
?雙DVX3159A 15”(381 mm)低頻換能器;靈敏度101 dB,最高137 dB SPL;系統額定值:持續功率1000 W,峰值功率4000 W;28個M10螺紋吊裝點;PI和FG型號提供壓蓋螺母蓋板和不銹鋼網罩。
覆蓋(-6dB標準) | Omnidirectional in normal operating range |
環境參數 | Standard versions: IEC 60529 IP44. PI and FG versions: IEC 60529 IP55 |
輸入連接 | Phoenix/Euroblock style screw terminals; PI and FG versions include dual-gland-nut input-panel cover |
額定阻抗 | Passive: N/A, Bi-amp: 4 Ω Biamp |
頻率響應(-3分貝) | 40 - 2600Hz |
頻率響應(-10分貝) | 30 - 3200Hz |
建議高通頻率 | 35Hz |
靈敏度(1瓦/1米) | 101dB |
最大. 聲壓級/1米 (計算) | 137dB |
覆蓋(-6dB標準)水平 | Omnidirectional dddd° |
覆蓋(-6dB標準)垂直 | Omnidirectional dddd° |
系統功率處理(連續/音樂//峰值) | 1000/2000/4000 Watts |
低頻換能器 | Two DVX3159A 15-inch (381 mm) drivers |
最小負荷阻抗 | Passive: N/A, Bi-amp: 2.7 Ω Biamp |
箱體材料 | 13-ply weather-resistant birch with EVCoat |
柵格 | Standard versions: 16-ga Galvanneal, Powdercoat, with screen behind. PI and FG versions: 18-ga Stainless, Powdercoat, with hydrophobic cloth behind |
吊掛 | (28) M10 Threaded Points (one EBK-M10-EVI kit of four forged eyebolts included) |
高度 | 768.6mm (30.26") |
寬度 | 675.6mm (26.6") |
深度 | 726.4mm (28.6") |
凈重 | 53.1kg (117.07lbs) |
