具有 1920x1080 的分辨率和 1600 萬色彩的 17 " 電容式觸摸屏 更快的處理速度和更大的內存 支持全動態視頻預覽和監視的 HDMI 和 XTP 輸入信號 兼容所有的 IP Link Pro 控制處理器
Extron TLP Pro 1720TG 是一款采用了電容式無邊框玻璃觸摸屏的 17" 桌面型觸控面板。這款可定制的觸摸屏具有更快的處理速度和更大的內存，其 1920x1080 的彩色電容式觸摸屏能夠提供鮮艷的外觀和更加靈敏的觸控表面。TLP Pro 1720TG 具有的視頻預覽輸入可支持來自 HDMI 信號源和 Extron XTP? 設備、符合 HDCP 標準的高分辨率視頻。觸摸屏可方便地通過單根以太網電纜獲取電源及進行通信。TLP Pro 1720TG 采用時尚的設計，其功能的特性使其非常適合用于需要一款完全可定制、帶有大尺寸控制面和多源視頻預覽功能的桌面型觸摸屏的控制應用環境。
特性
具有 1920x1080 的分辨率和 1600 萬色彩的 17" 電容式觸摸屏
更快的處理速度和更大的內存
支持全動態視頻預覽和監視的 HDMI 和 XTP 輸入信號
兼容所有的 IP Link Pro 控制處理器
觸摸屏可通過單根以太網電纜獲取電源及進行通信，無需本地電源 - 隨附電源合路器
內置揚聲器支持立體聲音頻
光感應器可根據環境照明的變化自動調整屏幕的亮度
可配置的紅色和綠色狀態指示燈用于指示房間的狀態：可用或正在使用
如果觸摸屏未與控制處理器通信，系統連接狀態指示燈就會提供視覺反饋
兩個高速 USB 2.0 接口
3.5 mm 耳機插孔為觸摸屏提供了本地音頻輸出
自動時鐘同步使觸摸屏能夠顯示準確的時間和日期
節能特性：
- 可調整的休眠計時器能讓觸摸屏進入休眠模式
- 運動探測器可將觸摸屏激活
可放置在桌面，或安裝在 VESA 支架上
| TLP Pro 1720TG | |
| Display | |
|---|---|
| | Active matrix TFT color display |
| | 17.3" (44.0 cm), measured diagonally |
| | 1920x1080 |
| | 127.7 dpi |
| | Widescreen |
| | 24-bit, 16.7 million colors |
| | 8 bit alpha channel |
| | 360 nits (cd/m2) |
| | 540:1 |
| | LED |
| | ±80° horizontal, +60°/-80° vertical |
| | Capacitive |
| Memory | |
| | 512 MB |
| | 512 MB |
| XTP – Interconnection between transmitter and receiver | |
| | TIA/EIA T568A or T568B |
| | 330' (100m) using CAT 5e/6/7 UTP or STP cable (24 AWG or better) |
| | Solid conductor, 24 AWG or better |
| | 400 MHz bandwidth, STP (Shielded Twisted Pair) |
| Video input | |
| | Up to 1920x1200*, 2K, or 1080p (HDTV) * reduced blanking |
| | 1 HDMI (HDCP compliant) 1 XTP |
| | 1 female HDMI type A 1 female RJ-45 (shared with Ethernet interface) |
| | 18.75 kHz to 75 kHz |
| | 24 Hz to 75 Hz |
| | DVI 1.0, HDMI, HDCP |
| | 48 kHz |
| Video processing | |
| | 8, 10, or 12 bits per channel; 165 MHz pixel clock |
| | 1 billion (10 bit processing) |
| Control — Touchpanel | |
| | On/off |
| | On/off |
| Control – Ethernet interface | |
| | 1 female RJ-45 connector (shared with XTP video input) |
| | 100Base-T, half/full duplex with autodetect |
| | DHCP, DNS, HTTP, HTTPS, ICMP, SFTP, SSH, TCP/IP, UDP/IP |
| | Link speed and duplex level: autodetected IP address = 192.168.254.251 Subnet mask = 255.255.255.0 Default gateway = 0.0.0.0 DHCP = off DNS = 127.0.0.1 |
| | |
| | Global Configurator Plus and Professional, GUI Designer |
| | Global Scripter |
| | Extron Control, iGVE |
| | GlobalViewer Enterprise, iGVE |
| | Toolbelt, Embedded Web page |
| Control — USB | |
| | 2 high-speed USB 2.0 devices |
| | 2 USB type A connectors |
| | USB 2.0, USB 1.1, USB 1.0 compatible |
| | Low speed (1.5 Mbps), full speed (12 Mbps) |
| Audio output – Speaker | |
| | 2 speakers (stereo), 86 dB SPL, 0.1 watt, 0.1 m, half space |
| | 750 Hz to 20 kHz, ±5 dB |
| | |
| | WAV (Microsoft RIFF) |
| | LPCM (uncompressed) |
| | Unsigned 8-bit, Signed 16-bit, Signed 24-bit, Signed 32-bit |
| | 2 kHz to 192 kHz |
| | Mono or stereo |
| Audio output – Line level | |
| | 1 stereo, unbalanced |
| | 1 female 3.5 mm stereo mini jack; tip (L), ring (R), sleeve (GND) |
| | 50 ohms unbalanced |
| | ±0.1 dB channel to channel |
| | -10 dBV (316 mVrms) |
| | >+8.2 dBV unbalanced at 1% THD+N |
| | >7.1 dBm unbalanced at 1% THD+N |
| General | |
| | PI 140 included |
| | 12 VDC or Power over Ethernet |
| Power consumption — Power injector (PI 140) with XTP | |
| | 32.5 watts |
| | 36.3 watts |
| Power consumption — Power supply (PS 1230) | |
| | 28.2 watts |
| | 35.7 watts |
| | Storage: 5 to +149 °F (-15 to +65 °C) / 10% to 90%, noncondensing Operating: +41 to +104 °F (5 to +40 °C) / 10% to 90%, noncondensing |
| | Convection, vents on rear (top and sides) |
| Thermal dissipation — Power injector (PI 140) | |
| | 106.0 BTU/hr |
| | 119.0 BTU/hr |
| Thermal dissipation — Power supply (PS 1230) | |
| | 91.1 BTU/hr |
| | 117.0 BTU/hr |
| | |
| | Set on tabletop or mount to optional VESA D 100 mm panel mount kit |
| | Tilts through a 40° range |
| | Plastic |
 | |
| | 12.4" H* x 17.5" W x 10.5" D (314 mm H* x 446 mm W x 266 mm D) (*Maximum height includes base. Total height and depth depends on screen tilt.) |
| | 15.8 lb (7,17 kg) |
| | ISTA 1A in carton (International Safe Transit Association) |
| | |
| | CE, c-UL, UL |
| | CE, C-tick,FCC Class A, ICES, VCCI |
| | Complies with the appropriate requirements of RoHS and WEEE. |
| | 3 years parts and labor; touchpanel display and overlay components are covered for 1 year |
| NOTE All nominal levels are at ±10%. | |
| NOTE Specifications are subject to change without notice. | |
